The SD8665QS is a quasi-resonant current mode PWM+PFM controller with built-in high voltage power MOSFET, and external sensing resistor, is applicable to SMPS applications.

The SD8665QS features multi-mode control., At heavy load condition. it operates in QR mode to reduce switch loss in the high line input voltage, and it operates with fixed frequency (65KHz) in CCM mode in the low line input voltage. At medium load or light load conditions, it works in QR+PFM mode to improve the conversion efficiency. At no load condition, it enters burst mode to reduce the standby power dissipation.

The SD8665QS has frequency jitter function for low EMI. The available peak current compensation function ensures the limit output power consistency even with different AC input voltages. The soft startup reduces the device stress during power-on process.

The SD8665QS integrates comprehensive protections including VCC overvoltage protection, output over-load protection, output overvoltage protection, leading edge blanking, cycle-by-cycle peak current limit, short circuit protection for output diode, AC input voltage undervoltage protection and over temperature protection, etc.

Main feature

QR mode for low EMI and low switch loss
PFM mode at light load condition for higher conversion efficiency
Entering burst mode at no load condition
Frequency rising at low voltage and heavy load condition for high limit output power
Frequency jitter for low EMI
Peak current compensation
Soft startup
VCC overvoltage protection
Output overload protection
Leading edge blanking
Cycle-by-cycle current limit
Output diode short protection
Undervoltage protection for AC input voltage
Adjustable output overvoltage protection
Over temperature protection

Ordering Information

Product Name	Package form	Marking	Hazardous Substance Control	Packing Type	Remarks
SD8665QS	EHSOP-5-325-1.7-3D	SD8665QS	Halogen free	Tube
SD8665QSTR	EHSOP-5-325-1.7-3D	SD8665QS	Halogen free	Tape&Reel

Block Diagram

SD8665QS 英文 (9000&3450, PS).png

Documents

title	Types of	Size (KB)	date	Download the latest English version
SD8665QS		0	2023-08-24	SD8665QS Brief Datasheet

Packages

EHSOP-5-325-1.7
